| Model | Unit | SDYG-Z0509 | SDYG-Z0510 | SDYG-Z0511 | SDYG-Z0513 | |
| Basic | Rated load | Q(kg) | 500 | 500 | 500 | 500 |
| Load centre distance | C(mm) | 400 | 400 | 400 | 400 | |
| Lifting method | Electric | Electric | Electric | Electric | ||
| Operating mode | Walking | Walking | Walking | Walking | ||
| Wheel | Materlal | Nylon/PU | Nylon/PU | Nylon/PU | Nylon/PU | |
| Wheelbase | y(mm) | 860 | 860 | 860 | 860 | |
| Front wheel spacing | b11(mm) | 380 | 380 | 380 | 380 | |
| Rear wheelbase | b10(mm) | 670 | 670 | 670 | 670 | |
| Steering wheel/weight bearing wheel/ balance wheel quantity | 02/2/6 | 02/2/6 | 02/2/6 | 02/2/6 | ||
| Load-bearing wheel size | mm | Φ70x60 | Φ70×60 | Φ70×60 | Φ70x60 | |
| Steering wheel size | mm | Φ100×50 | Φ100×50 | Φ100×50 | Φ100×50 | |
| Counterbalance wheel size | mm | Φ40×26 | Φ40×26 | Φ40×26 | Φ40×26 | |
| Auxiliary counterbalance wheel size | mm | Φ30×26 | Φ30×26 | Φ30×26 | Φ30×26 | |
| Dimensions | Minimum fork height from the ground | mm | 90 | 90 | 90 | 90 |
| Maximum fork height after lifting | h3(mm) | 900 | 900 | 900 | 900 | |
| Outside fork width | mm | 535 | 535 | 535 | 535 | |
| Inside fork width | mm | 225 | 225 | 225 | 225 | |
| Fork working length | l(mm) | 1150 | 1150 | 1150 | 1150 | |
| One side fork size | e/s(mm) | 155/60 | 155/60 | 155/60 | 155/60 | |
| Overall vehicle length | L1(mm) | 1600 | 1600 | 1600 | 1600 | |
| Overall width | b1(mm) | 790 | 790 | 790 | 790 | |
| Overall vehicle height (wlth forks lowered) | h1(mm) | 1200 | 1300 | 1400 | 1600 | |
| Overall vehicle height after gantry lift | h4(mm) | 2100 | 2300 | 2500 | 2900 | |
| Length to vertical side of forks | 12(mm) | 1150 | 1150 | 1150 | 1150 | |
| Min.turning radius | Wa(mm) | 1120 | 1120 | 1120 | 1120 | |
| Performance | Max.Iifting speed (full/no load) | mm/s | 80/110 | 80/110 | 80/110 | 80/110 |
| Max.descent speed (full/no load) | mm/s | 80/80 | 80/80 | 80/80 | 80/80 | |
| Electrical | Lifting motor | V/kw | 12/0.8 | 12/0.8 | 12/0.8 | 12/0.8 |
| Battery capacity | V/Ah | 12/33 | 12/33 | 12/33 | 12/33 | |
| Weight | Battery weight | kg | 10 | 10 | 10 | 10 |
| Self weight | kg | 175 | 186 | 197 | 219 | |
