| Model | Unit | CSD1.0T | CSD1.5T |
| Type of power | Lead-acid battery | Lead-acid battery | |
| Driving type | Side stand-on type | Side stand-on type | |
| Rated load | Q(kg) | 1000 | 1500 |
| Lifting height | h3(mm) | 6000 | 6000 |
| Overall length | L1(mm) | 2815 | 2965 |
| Overall width | bl/b2(mm) | 1450 | 1575 |
| Mast closed height | h1(mm) | 3350 | 3320 |
| Fork dimensions | s/e/l(mm) | 40/122/1070 | 45/125/1200 |
| Outside width of forks | b5(mm) | 700 | 760 |
| Free lifting height | h2(mm) | 2050 | 2095 |
| Max.height of mast during lifting(Including load backrest) | h4(mm) | 7340 | 7200 |
| Height of overhead guard | h6(mm) | 2270 | 2270 |
| Height of station board | b7(mm | 360 | 360 |
| Min.height of mast off the ground | mm | 130 | 50 |
| Height of vehicle off the ground | m(mm) | 40 | 40 |
| Battery,voltage/rated capacity | V/Ah | 48/400 | 48/420 |
| Weight of battery | kg | 655 | 665 |
| Vehicle weight (including battery) | kg | 5150 | 6150 |
| Driving motor power(S2-60min) | kw | 4.5(AC) | 6.5(AC) |
| Lifting motor power | kw | 6.3(DC) | 8.6(DC) |
| Tire | Polyurethane | Polyurethane | |
| Tire dimensions drive wheel | mm | Φ343×135 | Φ343×135 |
| Tire dimensions load wheel | mm | Φ140x100 | Φ140×127 |
| Dimension of balance wheel | mm | Φ180×76 | Φ180×76 |
| Number of wheel front/rear(x=drive wheel) | 4/1x-2 | 4/1x-2 | |
| Wheel track,drive side | mm | 805 | 805 |
| Wheel track,bear side | mm | 1220 | 1323 |
| Wheelbase | y(mm) | 1605 | 1700 |
| Load center | C(mm) | 500 | 600 |
| Front overhang | x{mm) | 618 | 645 |
| Tum radius | Wa(mm) | 1870 | 1968 |
| Stacking channel width(1t pallet 1000x1000)(1.5t pallet1200x1200) | Ast(mm) | 1500 | 1620 |
| Min.main channel(1tpallet 1000x1000)(1.5t pallet1200x1200) | Ast(mm) | 3400 | 3625 |
| Full load axie load,drive side/bear side | kg | 945/3975 | 2410/5240 |
| No-load axie load,drive side/load-bear side | kg | 2045/1275 | 2980/3170 |
| Driving speed,full load/no load | km/h | 7.8/8 | 7.8/8 |
| Lifting speed,full load/no load | mm/s | 140/260 | 140/300 |
| Descent speed,full load/no load | mm/s | 300/160 | 300/160 |
| Braking type | Electromagnetic brake | Electromagnetic brake | |
| Steering type | Electronic steering | Electronic steering | |
| Battery replacement method | Side pull type | Side pull type |
