Standard configuration:
· Curtis controller
·Bucher pump
·12#+C+J special section steel frame
·24V/85Ah maintenance free battery
·750W horizontal drive
·Handle walking up right
Model | Unit | CDD15A | |||
Performance | Load capacity | kg | 1500 | ||
Load center | mm | 600 | |||
Travel speed without load/with load | km/h | 4.5/3.5 | |||
Lifting speed without load/with load | mm/s | 140/80 | |||
Lowered speed without load/with load | mm/s | 100/80 | |||
Ascend slope ability without load/with load | % | 7/4 | |||
Dimensions | Overall length/width of frame | mm | 1860/850 | ||
Wheelbase | mm | 1250 | |||
Fork size(lengthxwidth xthickness) | mm | 1150×165×55 | |||
Fork outside width | mm | 550/685 | |||
Minimum ground clearance | mm | 28 | |||
Fork lowered height | mm | 90 | |||
Minimum turning radius | mm | 1530 | |||
Minimum intersecting aisie | mm | 2400 | |||
Wheel | Front wheel | mm | 80×70 | ||
Drive wheel | mm | 210x75 | |||
Caster wheel | mm | 115×55 | |||
Electrical Components | Drive motor Rated output/DC motor | kw | 0.75 | ||
Hoist motor Rated out put/DC motor | kw | 2.2 | |||
Battery | Voltage/Capacity | V/Ah | 24/85 | ||
Weight | kg | 26x2 | |||
Mast Type | Max.Lifting Helght | Mast Overall Height | Helght Mast Extended | Service Weight | |
Simplex Mast | 1600mm | 2080mm | 2080mm | 460kg | |
2-Stage Mast | 2000mm | 1580mm | 2550mm | 520kg | |
2500mm | 1830mm | 3050mm | 530kg | ||
3000mm | 2080mm | 3550mm | 540kg | ||
3500mm | 2330mm | 4050mm | 620kg |
