Standard configuration:
· Curtis controller
· Bucher pump
· 120x8mm C section steel frame
· 24V/100Ah maintenance free battery
· 750W horizontal drive
Model | Unit | CDD10G/15G | |||
Performance | Maximum load capacity | kg | 1000/1500 | ||
With load center at | mm | 600 | |||
Travel speed without load/with load | km/h | 4.5/3.5 | |||
Liffing speed without load/with load | mm/s | 110/80 | |||
Lowered speed without load/with load | mm/s | 100/100 | |||
Ascend slope abilty without load/with load | % | 7/4 | |||
Dimensions | Overall length/width of frame(without platform) | mm | 1910/850 | ||
Wheelbase | mm | 1270 | |||
Fork size(length xwidth xthickness) | mm | 10800×165×65 | |||
Fork outside width | mm | 550/685 | |||
Min frounf height | mm | 30 | |||
Fork lowered height | mm | 90 | |||
Minimum turning radius | mm | 1920 | |||
Minimum intersecting aisie | mm | 2795 | |||
Tire | Front wheel | mm | 80×70 | ||
Drive wheel | mm | 210×70 | |||
Caster wheel | mm | 115×55 | |||
Electrical Components | Drive motor Rated output/AC motor | kw | 0.75 | ||
Hoist motor Rated out put/DC motor | kw | 2.2 | |||
Battery | Voltag/Capacity | V/Ah | 24/100 | ||
Weight | kg | 31×2 | |||
Mast Type | Max.Fork Height | Mast Lowered | Mast Extended | Weight(kg) | |
CDD10/15G | CDD10/15G | CDD10/15G | CDD10/15G | ||
Simplex Mast (2 stage) | 1600 | 2080 | 2080 | 520/530 | |
2000 | 1580 | 2550 | 575/590 | ||
2500 | 1830 | 3050 | 610/620 | ||
3000 | 2080 | 3550 | 635/650 |
