| Model | Unit | YBQ-10 | YBQ-15 |
| Load capaclty | kg | 1000 | 1500 |
| Tractlon seat(hook)helght | mm | 187-333 | |
| Wheelbase | mm | 410 | |
| Drlve wheel slze | mm | Φ300X100 | |
| Directional wheel size | mm | Φ100X50 | |
| Unlversal wheel size | mm | Φ100X50 | |
| Drive wheel base | mm | 558 | |
| Minimum ground clearance | mm | 80 | |
| Handle height from the ground (max.&min.) | mm | 1170/715 | |
| Overall length | mm | 875 | |
| Overall width | mm | 660 | |
| Overall helght | mm | 1238 | |
| Turning radius | mm | 655 | |
| Battery voltage/capaclty | V/Ah | 24/85 | |
| Drive motor power | kw | 0.8 | 1.2 |
| Battery welght | kg | 45 | |
| Charger | V/A | 24/10 | |
| Drive motor controller | 1212S-2601 | 1237-2425 | |
| Noise | dB(A) | <70 | |
| Self-weight (including battery) | kg | 230 | 200 |
| Model | Unit | YBQ-10 | YBQ-15 |
| Load capaclty | kg | 1000 | 1500 |
| Tractlon seat(hook)helght | mm | 187-333 | |
| Wheelbase | mm | 410 | |
| Drlve wheel slze | mm | Φ300X100 | |
| Directional wheel size | mm | Φ100X50 | |
| Unlversal wheel size | mm | Φ100X50 | |
| Drive wheel base | mm | 558 | |
| Minimum ground clearance | mm | 80 | |
| Handle height from the ground (max.&min.) | mm | 1170/715 | |
| Overall length | mm | 875 | |
| Overall width | mm | 660 | |
| Overall helght | mm | 1238 | |
| Turning radius | mm | 655 | |
| Battery voltage/capaclty | V/Ah | 24/85 | |
| Drive motor power | kw | 0.8 | 1.2 |
| Battery welght | kg | 45 | |
| Charger | V/A | 24/10 | |
| Drive motor controller | 1212S-2601 | 1237-2425 | |
| Noise | dB(A) | <70 | |
| Self-weight (including battery) | kg | 230 | 200 |
