multiple safety devices: emergency lowering valve, overload protection, hydraulic pipe burst protection and screw-type leveling outriggers. Non-slip platform and foldable guardrail enhance safety; sealed hydraulic cylinders and rust-resistant structure reduce maintenance and extend service life.
Factories & workshops: Equipment installation, pipeline maintenance, lighting repair and production line assembly, suitable for long-distance operations.
Warehouses & logistics centers: High-level cargo handling, shelf maintenance, inventory counting, adapting to narrow aisles and uneven ground.
Malls, exhibition halls, hotels: Lamp replacement, ceiling maintenance, sign installation, decoration and stage setup (low noise, no impact on business).
Airports, stations, stadiums: Terminal maintenance, lighting/sound installation and public facility inspection.
Office buildings, communities: Exterior cleaning, window/AC installation, street lamp repair, garden trimming and fire equipment maintenance.
Construction sites: Small high-altitude construction, wall painting and material transportation, adapting to slopes and rough ground.
Municipal facilities: Street lamp/traffic signal maintenance, road sign installation and power/communication line inspection.
Special scenarios: Emergency maintenance, high-altitude photography and temporary operations where traditional equipment is inaccessible.
| Model | Unit | SJY0.5-7A | SJY0.5-9A | SJY0.5-11A | SJY0.3-13A | SJY0.5-12A | SJY0.5-14A | SJY0.4-16A |
| Rated capacity | kg | 500 | 300 | 500 | 400 | |||
| Max.platform height | mm | 7000 | 9000 | 11000 | 12850 | 12000 | 14000 | 16000 |
| Min.platform height | mm | 1120 | 1240 | 1370 | 1495 | 1656 | 1835 | 2430 |
| Working platform | mm | 2150×1140 | 2500×1260 | 2750x1600 | ||||
| Unfolding size | mm | 2130×2890 | 2560×2890 | 3520x4140 | ||||
| Lift motor | V/kw | 48/2.2 | 48/3 | |||||
| Drive motor rating | V/kw | 48/2.5 | 48/3.5 | |||||
| Voltage | V | 48 | ||||||
| Driving speed | km/h | 3.5-4.5 | ||||||
| Max.gradeability | % | 10-15 | ||||||
| Battery | V/Ah | 12/70×4 | 12/110x4 | |||||
| Charger | v/A | 48/8 | 48/15 | |||||
| Overall length | mm | 2250 | 2558 | 3020 | ||||
| Overall width | mm | 1300 | 1410 | 1960 | ||||
| Overall height | mm | 2120 | 2240 | 2370 | 2495 | 2650 | 2987 | 3530 |
| Overall weight | kg | 1120 | 1320 | 1680 | 1980 | 2040 | 2860 | 3750 |
