| Product name | Model | Max.working height(m) | Max.platform height(m) | Safe load capacity(kg) | Table size(m) | Overall dimensions(m) | Opening size of outriggers(m) | Total weight(kg) |
| Single -mast | GTWW04-100-1 | 6 | 4 | 150 | 0.65x0.65x1.1 | 1.42x0.78x1.97 | 1.702x1.914 | 344 |
| GTWY06-1 | 8 | 6 | 150 | 0.65x0.65x1.1 | 1.42x0.78x1.97 | 1.702x1.914 | 370 | |
| GTWYO8-1 | 10 | 8 | 130 | 0.65x0.65x1.1 | 1.42x0.78x1.97 | 1.702x1.914 | 388 | |
| GTWY10-1 | 12 | 10 | 130 | 0.65x0.65x1.1 | 1.42x0.78x1.97 | 1.702x1.914 | 441 | |
| Double -mast | GTWY06-2 | 8 | 6 | 300 | 1.2x0.63x1.1 | 1.55x0.85x2 | 1.694x1.814 | 588 |
| GTWY08-2 | 10 | 8 | 300 | 1.2x0.63x1.1 | 1.55x0.85x2 | 1.694x1.814 | 664 | |
| GTWY10-2 | 12 | 10 | 250 | 1.5x0.63x1.1 | 1.84x0.85x2 | 1.954x2.295 | 726 | |
| GTWY12-2 | 14 | 12 | 200 | 1.5x0.63x1.1 | 1.84x0.85x2 | 1.954x2.295 | 764 | |
| GTWY14-2 | 16 | 14 | 150 | 1.5x0.63x1.1 | 1.95x1.05x2.35 | 2.24x2.41 | 902 | |
| Three -mast | GTWY10-3 | 12 | 10 | 250 | 1.45x0.9x1 | 1.65x1.3x1.9 | 2.22x2.27 | 980 |
| GTWY12-3 | 14 | 12 | 300 | 1.457x0.88x1. | 1.845x1.1x2 | 2.22x2.27 | 1050 | |
| GTWY14-3 | 16 | 14 | 250 | 1.54x0.94x1.1 | 1.798x1.15x2.37 | 2.945x2.58 | 1120 | |
| GTWY16-3 | 18 | 16 | 150 | 1.54x0.94x1.1 | 1.798x1.15x2.37 | 2.945x2.58 | 1200 |
| Product name | Model | Max.working height(m) | Max.platform height(m) | Safe load capacity(kg) | Table size(m) | Overall dimensions(m) | Opening size of outriggers(m) | Total weight(kg) |
| Single -mast | GTWW04-100-1 | 6 | 4 | 150 | 0.65x0.65x1.1 | 1.42x0.78x1.97 | 1.702x1.914 | 344 |
| GTWY06-1 | 8 | 6 | 150 | 0.65x0.65x1.1 | 1.42x0.78x1.97 | 1.702x1.914 | 370 | |
| GTWYO8-1 | 10 | 8 | 130 | 0.65x0.65x1.1 | 1.42x0.78x1.97 | 1.702x1.914 | 388 | |
| GTWY10-1 | 12 | 10 | 130 | 0.65x0.65x1.1 | 1.42x0.78x1.97 | 1.702x1.914 | 441 | |
| Double -mast | GTWY06-2 | 8 | 6 | 300 | 1.2x0.63x1.1 | 1.55x0.85x2 | 1.694x1.814 | 588 |
| GTWY08-2 | 10 | 8 | 300 | 1.2x0.63x1.1 | 1.55x0.85x2 | 1.694x1.814 | 664 | |
| GTWY10-2 | 12 | 10 | 250 | 1.5x0.63x1.1 | 1.84x0.85x2 | 1.954x2.295 | 726 | |
| GTWY12-2 | 14 | 12 | 200 | 1.5x0.63x1.1 | 1.84x0.85x2 | 1.954x2.295 | 764 | |
| GTWY14-2 | 16 | 14 | 150 | 1.5x0.63x1.1 | 1.95x1.05x2.35 | 2.24x2.41 | 902 | |
| Three -mast | GTWY10-3 | 12 | 10 | 250 | 1.45x0.9x1 | 1.65x1.3x1.9 | 2.22x2.27 | 980 |
| GTWY12-3 | 14 | 12 | 300 | 1.457x0.88x1. | 1.845x1.1x2 | 2.22x2.27 | 1050 | |
| GTWY14-3 | 16 | 14 | 250 | 1.54x0.94x1.1 | 1.798x1.15x2.37 | 2.945x2.58 | 1120 | |
| GTWY16-3 | 18 | 16 | 150 | 1.54x0.94x1.1 | 1.798x1.15x2.37 | 2.945x2.58 | 1200 |
