Features:
Proportional contorls
Automatic pothole protection
Driveable at full height
Non-marking tyre
Automatic brake system
Emergency lowering system
Emergency stop button
Cylinder holding valve
Onboard diagnostic system
Model | Unit | AMWP6-1100 | AMWP7.5-1100 |
Max.working height | m | 8 | 9.5 |
Max.platform height | m | 6 | 7.5 |
Loading capacity | kg | 150 | 125 |
Occupants | 1 | 1 | |
Overall length | m | 1.4 | 1.4 |
Overall width | m | 0.76 | 0.76 |
Overall height | m | 1.99 | 1.99 |
Platform dimension | m | 0.66×0.67 | 0.66×0.67 |
Wheel base | m | 1.07 | 1.07 |
Turning radius | m | 0.3 | 0.3 |
Travel speed(stowed) | km/h | 3.5 | 4 |
Travel speed(raised) | km/h | 0.8 | 1.1 |
Up/down speed | sec | 48/40 | 53/45 |
Gradeability | % | 25 | 25 |
Drive tyres | mm | Φ305×100 | Φ305×100 |
Drive motors | 2×24VDC/0.5kw | 2×24VDC/0.5kw | |
Liftlng motor | 24VDC/1.2kw | 24VDC/1.2kw | |
Battery | V/Ah | 2×12V/100Ah | 2x12V/100Ah |
Charger | V/A | 24/15 | 24/15 |
Weight | kg | 1120 | 1190 |
Features:
Proportional contorls
Automatic pothole protection
Driveable at full height
Non-marking tyre
Automatic brake system
Emergency lowering system
Emergency stop button
Cylinder holding valve
Onboard diagnostic system
Model | Unit | AMWP6-1100 | AMWP7.5-1100 |
Max.working height | m | 8 | 9.5 |
Max.platform height | m | 6 | 7.5 |
Loading capacity | kg | 150 | 125 |
Occupants | 1 | 1 | |
Overall length | m | 1.4 | 1.4 |
Overall width | m | 0.76 | 0.76 |
Overall height | m | 1.99 | 1.99 |
Platform dimension | m | 0.66×0.67 | 0.66×0.67 |
Wheel base | m | 1.07 | 1.07 |
Turning radius | m | 0.3 | 0.3 |
Travel speed(stowed) | km/h | 3.5 | 4 |
Travel speed(raised) | km/h | 0.8 | 1.1 |
Up/down speed | sec | 48/40 | 53/45 |
Gradeability | % | 25 | 25 |
Drive tyres | mm | Φ305×100 | Φ305×100 |
Drive motors | 2×24VDC/0.5kw | 2×24VDC/0.5kw | |
Liftlng motor | 24VDC/1.2kw | 24VDC/1.2kw | |
Battery | V/Ah | 2×12V/100Ah | 2x12V/100Ah |
Charger | V/A | 24/15 | 24/15 |
Weight | kg | 1120 | 1190 |
