| Model | Unit | GTWT08-E | GTWY10-E | GTWY08-E | GTWY10-E |
| Max.working height | m | 10 | 12 | 10 | 12 |
| Max.platform height | m | 8 | 10 | 8 | 10 |
| Safe load capacity | kg | 130 | 130 | 300 | 250 |
| Platform slze(length×width ×helght) | m | 0.65×0.65x1.1 | 0.65×0.65×1.1 | 1.2×0.63×1.1 | 1.5×0.63×1.1 |
| Overall dimensions(lengthxwidthxheight) | m | 1.8×0.78×1.97 | 1.8×0.78×1.97 | 1.8×0.85×2 | 2.16x0.85x2 |
| Opening size of outriggers | m | 2.028×1.914 | 2.028×1.914 | 2.02×1.814 | 2.28×2.259 |
| Total weight | kg | 405 | 436 | 685 | 753 |
| Max.number of workers | 1 | 1 | 2 | 2 | |
| Min.ground clearance | m | 0.05 | 0.05 | 0.06 | 0.06 |
| Wheelbase | m | 1.67 | 1.67 | 1.55 | 1.55 |
| Lifting motor | V/kw | 220/1.1 | 220/1.1 | 220/1.5 | 220/1.5 |
| Tires | 6 inches | Front tire 8 inches Back tire 7 inches | |||
| Lifting speed | m/min | 3-5 | |||
| Platform materlal | 40×20×1.5 | ||||
| Rectangular steer tube | 3 | ||||
| Hydraulic cylinder | Hebei Hengyu | ||||
| Hydraulic pump station | Anshan Lisheng | ||||
| Material of aluminum mast | The thickness of aluminum alloy`ls 6.5 | ||||
| Electrlical equipment | Remote Control Distribution Box | ||||
| Bottom frame | Q235 Steel | ||||
