Features:
Proportional contorls
Automatic pothole protection
Driveable at full height
Non-marking tyre
Automatic brake system
Emergency lowering system
Emergency stop button
Cylinder holding valve
Onboard diagnostic system
| Model | Unit | AMWP7.5-2100 | AMWP9-2100 |
| Max.working height | m | 9.5 | 11 |
| Max.platform height | m | 7.5 | 9 |
| Loading capacity | kg | 200 | 150 |
| Occupants | 1 | 1 | |
| Overall length | m | 1.46 | 1.46 |
| Overall width | m | 1.01 | 1.01 |
| Overall height | m | 1.99 | 1.99 |
| Platform dimension | m | 1×0.65 | 1×0.65 |
| Wheel base | m | 1.14 | 1.14 |
| Turning radius | m | 0.3 | 0.3 |
| Travel speed(stowed) | km/h | 4 | 4 |
| Travel speed(raised) | km/h | 1.1 | 1.1 |
| Up/down speed | sec | 48/40 | 56/49 |
| Gradeability | % | 25 | 25 |
| Drive tyres | mm | Φ305×100 | Φ305×100 |
| Drive motors | 2×24VDC/0.5kw | 2×24VDC/0.5kw | |
| Liftlng motor | 24VDC/1.2kw | 24VDC/1.2kw | |
| Battery | V/Ah | 2x12V/100Ah | 2×12V/100Ah |
| Charger | V/A | 24/15 | 24/15 |
| Weight | kg | 1270 | 1345 |
Features:
Proportional contorls
Automatic pothole protection
Driveable at full height
Non-marking tyre
Automatic brake system
Emergency lowering system
Emergency stop button
Cylinder holding valve
Onboard diagnostic system
| Model | Unit | AMWP7.5-2100 | AMWP9-2100 |
| Max.working height | m | 9.5 | 11 |
| Max.platform height | m | 7.5 | 9 |
| Loading capacity | kg | 200 | 150 |
| Occupants | 1 | 1 | |
| Overall length | m | 1.46 | 1.46 |
| Overall width | m | 1.01 | 1.01 |
| Overall height | m | 1.99 | 1.99 |
| Platform dimension | m | 1×0.65 | 1×0.65 |
| Wheel base | m | 1.14 | 1.14 |
| Turning radius | m | 0.3 | 0.3 |
| Travel speed(stowed) | km/h | 4 | 4 |
| Travel speed(raised) | km/h | 1.1 | 1.1 |
| Up/down speed | sec | 48/40 | 56/49 |
| Gradeability | % | 25 | 25 |
| Drive tyres | mm | Φ305×100 | Φ305×100 |
| Drive motors | 2×24VDC/0.5kw | 2×24VDC/0.5kw | |
| Liftlng motor | 24VDC/1.2kw | 24VDC/1.2kw | |
| Battery | V/Ah | 2x12V/100Ah | 2×12V/100Ah |
| Charger | V/A | 24/15 | 24/15 |
| Weight | kg | 1270 | 1345 |
