Product advantages:
· High-power travel drive wheel
· High-power hydraulic pump station, strong power, maintenance-free colloid battery,long-lasting power
· High-quality oll cylinder, heavy-duty design, boom distance is adjusted by oll cylinder.Easy and convenient
· Equipped with a safety valve, can be folded and packed in a small volume
· Suitable for operation in areas that are difficult for forklifts to enter
Model CDYE | Unit | A | B | C | D | E | F | |
0° | Boom length | mm | 1440 | 2300 | 2500 | 2500 | 2900 | 3100 |
Load capacity | kg | 1000 | 342 | 290 | 290 | 220 | 200 | |
40° | Boom length | mm | 1004 | 1638 | 1787 | 1935 | 2083 | 2231 |
Load capacity | kg | 1100 | 565 | 430 | 345 | 290 | 250 | |
Leg inner width | mm | 985 | ||||||
Leg outer width | mm | 1170 | ||||||
Weight | kg | 568 |
Product advantages:
· High-power travel drive wheel
· High-power hydraulic pump station, strong power, maintenance-free colloid battery,long-lasting power
· High-quality oll cylinder, heavy-duty design, boom distance is adjusted by oll cylinder.Easy and convenient
· Equipped with a safety valve, can be folded and packed in a small volume
· Suitable for operation in areas that are difficult for forklifts to enter
Model CDYE | Unit | A | B | C | D | E | F | |
0° | Boom length | mm | 1440 | 2300 | 2500 | 2500 | 2900 | 3100 |
Load capacity | kg | 1000 | 342 | 290 | 290 | 220 | 200 | |
40° | Boom length | mm | 1004 | 1638 | 1787 | 1935 | 2083 | 2231 |
Load capacity | kg | 1100 | 565 | 430 | 345 | 290 | 250 | |
Leg inner width | mm | 985 | ||||||
Leg outer width | mm | 1170 | ||||||
Weight | kg | 568 |
