Standard configuration:
· 48V/65Ah maintenance-free gel battery
·1kW AC horizontal drive
·Emergency reverse button
·Forks can be customized and extended
· All-iron cover, high body structure strength
Model | Unit | CBD-C | |
Characteristlc | Operatlon mode | Stand-up | |
Rated load capacity | Q(kg) | 2000 | |
Lift height | h3(mm) | 205 | |
Weight | kg | 320 | |
Load center distance | c(mm) | 600 | |
Front overhang | x(mm) | 971 | |
Wheelbase | y(mm) | 1151 | |
Controller | 48S09/10 | ||
Wheels | Tire type | PU | |
Drive wheel slze | Φx w(mm) | Φ210×70 | |
Carrying wheel size | Φx w(mm) | Φ80x60 | |
Balance wheel size | Φx w(mm) | Φ70×40 | |
Number of driving wheels,balance wheels/carrying wheels (x=drlving wheels) | 1x,2/4 | ||
Dimensions | Minimum height of fork | h 13(mm) | 85 |
Vehicle length | L1(mm) | 2033 | |
Body length | L2(mm) | 313 | |
Vehicle width | b1/b2(mm) | 762 | |
Fork size | s/e/I(mm) | 55/165/1220 | |
Fork outer width | b5(mm) | 550/685 | |
Ground clearance at wheelbase center | m2(mm) | 30 | |
Aisle width:1000x1200 pallets(1200 placed along the forks) | Ast(mm) | 2570 | |
Alsle width:800x1200 pallets(1200 placed along the forks) | Ast(mm) | 2481 | |
Turning radius | Wa(mm) | 1820 | |
Performance | Travellng speed,full/unloaded | km/h | 5/5.5 |
Lift speed,full load/no load | mm/s | 25 | |
Descending speed,full/unloaded | mm/s | 30 | |
Maximum gradeabilty,full/unladen | % | 2024/5/16 | |
Brake type | Electromagnetic brake | ||
Drive & Battery | Drive motor power | kw | 1 |
Lifting motor power | kw | 0.8 | |
Battery voltage/capacity | V/Ah | 48/65 | |
Battery weight | kg | 15×4 | |
Others | Noise level | dB(A) | 69 |
Steering type | Mechanical steerlng |
