| Quantitas: | |
|---|---|
Remarks:
· Longitudo L1 auctus per 65mme
· De deinceps distantiam diminuitur a 60mm et latitudo in stacking channel augetur per 65mm
· Max, extra spatio furca quod 700mm
| Exemplar | Unitas | Cqd15c | Cqd20c | Cqd20c |
| Typus of Power | Plumbum-acidum altilium | Plumbum, acld altilium | Plumbum, acld altilium | |
| Driving type | Parte sto-super type | Slde stare-super type | Parte sto-super type | |
| Rated onus | Q (kg) | 1500 | 2000 | 2000 |
| ALTER | H3 (mm) | 6000 | 6000 | 3000 |
| Altiore Longitudo | L1 (mm) | 2355 | 2385 | 2385 |
| Altiore width | B1 / B2 (mm) | 1090 | 1090 | 1090 |
| Furca dimensiones | S / E / L (mm) | 35/100/100/1070 | 40/122/1070 | 40/122/1070 |
| Foris latitudinem fuscinulas | B5 (mm) | 240-700 | 266-700 | 266-700 |
| Inside Width of Support Crura | B4 (mm) | 802 | 802 | 802 |
| Et Tark inniti deinceps / retrorsum | 2/4 | 2/4 | 2/4 | |
| Mast clausa altitudo | H1 (mm) | 2631 | 2631 | 2100 |
| Liberum elevatio altitudinis | H2 (mm) | 2030 | 2030 | |
| Et Max.height de Malus Per Elevatis (including onus backrest) | H4 (mm) | 7005 | 7005 | 4055 |
| Width of onus backrest | B3 (mm) | 950 | 950 | 950 |
| Altitudo caput praesidio | H6 (mm) | 2265 | 2265 | 2265 |
| Altitudo autem Station Board | H7 (mm) | 350 | 350 | 350 |
| RCTD distantiam | L4 (mm) | 550 | 620 | 620 |
| Min.height de Malo off in terra | mm | 107 | 107 | 107 |
| Altitudo vehiculum off terram | M (mm) | 65 | 65 | 65 |
| Pugna, voltage / rated capacity | V / ah | 24/280 | 24/280 | 24/280 |
| Pondus altilium | kg | 245 | 245 | 245 |
| Vehiculum pondus (including altilium) | kg | 2540 | 2700 | 2360 |
| Coegi motor potentia (S2-60min) | KW | 22 | 22 | 22 |
| Elevatis motricium potestate | KW | 3 | 3 | 3 |
| Strideo | Polyurethane | Polyurethane | Polyurethane | |
| Tyrum dimensiones eiciam rota | mm | Φ210 × LXXXV | Φ CCX × LXXXV | Φ CCX × LXXXV |
| Tyri Dimensions onus rotam | mm | × × CC CCXXXV | × × CC CCXXXV | × × CC CCXXXV |
| Dimensionem statera rotam | mm | Φ CL × L | Φ CL × L | Φ CL × L |
| Numerus rotam fronte / tergo (x = DRLVE rota) | II / 1x-II | II / 1x-II | II / 1x-II | |
| Rota track, eiciam partem | mm | 693 | 693 | 693 |
| Rota track, porta | mm | 989 | 989 | 989 |
| Wheelbase | y (mm) | 1434 | 1554 | 1554 |
| Onus centrum | C (mm) | 500 | 500 | 500 |
| Front Overhang | X (mm) | 194 | 174 | 152 |
| Tun Radli | WA (mm) | 1682 | 1800 | 1800 |
| Stacking channel width (grabatum 1000x1200) MCC Coss-furca directionem | Ast (mm) | 2775 | 2830 | 2820 |
| Stacking channel width (Pallet800x1200) MCC per furca dlriderlon | Ast (mm) | 2830 | 2865 | 2845 |
| Plena axie onus, furca deinceps, eiciam partem / beu slde | kg | 569/3471 | 583/4117 | 557/3813 |
| Plena axie onus, furca recuperatio, agitare latus / beat latus | kg | 1305/2735 | 1770/2930 | 1608/2762 |
| Non-onus axie onus, eiciam slde / onus-ursus | kg | 1670/870 | 1842/858 | 1618/742 |
| Drivng celeritate, plena onus / non onus | M / h | 4.0 / 5.0 | 4.0 / 5.0 | 4.0 / 5.0 |
| Elevatis celeritas, plena onus / non onus | mm / s | 80/150 | 75/150 | 75/150 |
| Descensus celeritate, plena onus / non onus | mm / s | 160/105 | 200/105 | 200/105 |
| Max.Climbing, plena onus / non onus (S2-5MIM) | % | 5.0 / 8,0 | 4.0 / 8.0 | 4.0 / 8.0 |
| Braking type | Brake electromagnetic | Brake electromagnetic | Brake electromagnetic | |
| Steering Type | Electronic Steering | Electronic Steering | Electronic Steering | |
| Pugna replacement modum | Latus viverra type | Latus viverra type | Latus viverra type |
