The EPT15/20 is a lithium-ion electric pallet truck built for light to medium-duty material handling, with a rated capacity of 1500kg to 2000kg. It combines fast charging, zero maintenance, and lightweight maneuverability, making it a versatile pallet jack for warehouses, retail floors, and cold storage.
The EPT15/20 series represents the next generation of lithium-ion powered electric pallet trucks, designed for light to medium-duty material handling with the advantages of fast charging, zero maintenance, and lightweight maneuverability. With a fork size of 1150×160×50mm and a turning radius as low as 1380mm, this electric pallet truck moves efficiently through narrow aisles and compact spaces.
A lithium-ion electric pallet truck is a motorized pallet jack powered by a rechargeable lithium battery instead of a lead-acid battery or manual hydraulics. Compared to lead-acid models, lithium-ion units like the EPT15/20 charge faster, require no watering or acid maintenance, and perform better in low temperatures.
The EPT15/20 electric pallet truck is suited to five main environments, from high-traffic warehouses to sensitive cold storage and food-grade facilities. Its clean lithium battery, quiet PU wheels, and lightweight build make it adaptable across industries.
High-frequency pallet movement on smooth concrete/epoxy floors
Narrow aisle operation with turning radius as low as 1350mm
Quiet operation (PU wheels) – suitable for business-hours use
Compact size for narrow retail stockrooms
Lightweight (as low as 142kg) – fits on truck tail lifts
Fast charging in truck cabin or at depot
Clean lithium battery – safe for food/pharma environments
No fumes or acid spills
Lithium battery performs better in low temperatures than lead-acid
Sealed design resists moisture
The EPT15/20 pallet jack comes with a patented battery side-pull mechanism, a maintenance-free brushless motor, and an intelligent control system for simple, reliable operation.
Standard configuration:
Imported driving force, strong power
48V maintenance-free brushless motor system
An integrated battery side pull mechanism that has obtained national patents
Adopting a multifunctional intelligent controller and control system, practical and simple
Model | Unit | EPT15/20 |
|---|---|---|
Operation type | Walking style | |
Rated capacity | kg | 1500 / 2000 |
Load center distance | mm | 600 |
Front overhang | X | 946 |
Wheel base | y | 2000 |
Weight | kg | 120 / 130 |
Load per axle (driving/bearing) laden | kg | 500 / 1100 |
Load per axle unladen | kg | 120 / 130 |
Material | PU | |
Number of wheels | 1/4 | |
Drive wheel size | mm | φ160×55 |
Load wheel size | mm | φ80×70 |
Lift height | h3 (mm) | 115 |
Overall length | l1 (mm) | 1590 |
Body length (no forks) | l2 (mm) | 440 |
Fork outer width | b1 (mm) | 560 / 685 |
Fork size | s/e/l (mm) | 50/160/1150 |
Min. ground clearance | mm | 28 |
Right-angle stacking channel width (pallet 800×1200 along fork) | Ast (mm) | 2155 |
Turning radius | mm | 1380 |
Driving speed laden/unladen | km/h | 4.0/5.0 |
Lifting speed laden/unladen | mm/s | 20/25 |
Descent speed laden/unladen | mm/s | 50/40 |
Cycling work time | h | ≥4 |
Service brake | Electromagnetic brake | |
Drive motor power | kw | 0.8 |
Pump motor power | kw | 0.75 |
System voltage | V | 48 |
Control type | Electrically controlled | |
Noise level | dB | ≤70 |
Q: How much can the EPT15/20 electric pallet truck lift?
A: The EPT15/20 has a rated loading capacity of 1500kg (EPT15) or 2000kg (EPT20), with a 600mm load center distance, making it ideal for light to medium-duty pallet handling.
Q: Why choose a lithium-ion pallet jack over a lead-acid one?
A: Lithium-ion pallet jacks like the EPT15/20 charge faster, require zero maintenance (no acid or watering), run cleaner for food and pharma settings, and hold performance better in cold storage than lead-acid models.
Q: Can the EPT15/20 operate in narrow aisles?
A: Yes. With a turning radius of 1380mm and a compact body length of 440mm (excluding forks), the EPT15/20 is designed for narrow aisle and tight stockroom operation.
Q: How quiet is the EPT15/20 for retail use?
A: The EPT15/20 runs at a noise level of ≤70 dB with PU wheels, making it suitable for quiet operation during business hours in retail and supermarket environments.
Interested in the EPT15/20 Lithium-Ion Electric Pallet Truck? Contact MAIHUI or submit a product inquiry for pricing and specifications.
