Model | Unit | HS5020 | HS5021 |
Rated traction weight | kg | 80 | 150 |
Lift height | mm | 1100 | 1100 |
Load center | mm | 250 | 250 |
Lowered height | mm | 70 | 70 |
Forkleg height | mm | 100 | 100 |
Fork length | mm | 500 | 500 |
Fork width | mm | 50 | 50 |
Platform dimentions | mm | 500×530×90 | 500×530×90 |
Adjustable fork range | mm | 132-520 | 132-520 |
Bearing wheel size | mm | 100×30 | 100x30 |
Driving wheel size | mm | 100×30 | 100×30 |
Overall vehicle dimentions | mm | 865×550×1470 | 830×580×1470 |
Weight | kg | 52 | 62 |
Model | Unit | HS5020 | HS5021 |
Rated traction weight | kg | 80 | 150 |
Lift height | mm | 1100 | 1100 |
Load center | mm | 250 | 250 |
Lowered height | mm | 70 | 70 |
Forkleg height | mm | 100 | 100 |
Fork length | mm | 500 | 500 |
Fork width | mm | 50 | 50 |
Platform dimentions | mm | 500×530×90 | 500×530×90 |
Adjustable fork range | mm | 132-520 | 132-520 |
Bearing wheel size | mm | 100×30 | 100x30 |
Driving wheel size | mm | 100×30 | 100×30 |
Overall vehicle dimentions | mm | 865×550×1470 | 830×580×1470 |
Weight | kg | 52 | 62 |
