Warehouses & Storage Centers: High-level stacking (2.5-3m) of wide pallets, bulky goods and medium-heavy cargo (1-2T), effectively utilizing vertical storage space and improving warehouse capacity.
Factory Workshops: Transfer and high-level storage of raw materials, semi-finished products and finished products (such as large cartons, plastic barrels, mechanical parts), especially suitable for irregular and wide-size goods handling.
Logistics & Distribution Stations: Loading and unloading of wide pallets, high-level temporary stacking of goods, and short-distance transfer, ensuring stable operation during cargo lifting and moving.
Wholesale Markets & Supermarkets: High-level replenishment of bulky goods (such as household appliances, large packages), stacking of wide pallets in back-store warehouses, and stable handling in narrow passages.
Light Industry & Furniture Industry: Handling of large-size products (such as furniture, large packaging materials), high-lifting stacking and workstation transfer, with wide base legs ensuring safety during operation.
Small & Medium Enterprises: Daily medium-heavy load handling and high-level storage, no power dependence, suitable for workshops and warehouses with limited power supply or budget.
| Model | Unit | CTY-EWH (1400) |
| Rated lifting capacity | kg | 1000 |
| Max.lifting height | mm | 2000/2500/3000 |
| Lowered height of forks | mm | 90 |
| Fork length | mm | 900 |
| Adjustable width of fork | mm | 340-1490 |
| Lifting speed | mm/stroke | 20 |
| Lowering speed | mm/stroke | Adjustable |
| Outer width of front legs | mm | 1400 |
| Operation power of crank | kg | 24 |
| Front wheel size | mm | Φ74×52 |
| Rear wheel size | mm | Φ180×50 |
| Overall size | mm | 1410×1500×1540/1410×1500x1790/1410×1500×2040 |
