| Model | HW1000D | HW2000D | HW4000D |
| Rated lifting capacity(kg) | 1000 | 2000 | 4000 |
| Min.height(mm) | 305 | 360 | 400 |
| Max.height(mm) | 1780 | 1780 | 2050 |
| Platfom size(mm) | 1300x820 | 1300x850 | 1700x1200 |
| Base size(mm) | 1240x640 | 1220x785 | 1600x900 |
| Elevating power(sec) | 35-45 | 35-45 | 55-65 |
| Power parameters(s) | 380V/50Hz | 380V/50Hz | 380V/50Hz |
| Net weight(kg) | 210 | 290 | 520 |
| Model | HW1000D | HW2000D | HW4000D |
| Rated lifting capacity(kg) | 1000 | 2000 | 4000 |
| Min.height(mm) | 305 | 360 | 400 |
| Max.height(mm) | 1780 | 1780 | 2050 |
| Platfom size(mm) | 1300x820 | 1300x850 | 1700x1200 |
| Base size(mm) | 1240x640 | 1220x785 | 1600x900 |
| Elevating power(sec) | 35-45 | 35-45 | 55-65 |
| Power parameters(s) | 380V/50Hz | 380V/50Hz | 380V/50Hz |
| Net weight(kg) | 210 | 290 | 520 |
