| Model | HW500L | HW501L | HW502L | HW2000L | HW4000L | HW8000L |
| Rated lifting capacity(kg) | 500 | 500 | 500 | 2000 | 4000 | 8000 |
| Min.height(mm) | 200 | 180 | 180 | 205 | 230 | 300 |
| Max.height(mm) | 1000 | 1000 | 1000 | 1000 | 1000 | 1050 |
| Platform size(mm) | 2000x800 | 1300x600 | 1300x800 | 2500x820 | 2500x850 | 3400x1200 |
| Base size(mm) | 1615x950 | 1210x585 | 1210x585 | 2460x640 | 2450x785 | 2500x900 |
| Elevating power(sec) | 16-26 | 10-15 | 10-15 | 26-36 | 36-46 | 36-46 |
| Power parameters(s) | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz |
| Net weight(kg) | 193 | 121 | 131 | 265 | 360 | 560 |
