Model | WP350A | WPS350AA | WP500A |
Load capacity(kg) | 350 | 350 | 500 |
Lowest height(mm) | 360 | 360 | 360 |
Max.height(mm) | 1300 | 1500 | 1580 |
Table dimensions(mm) | 905x500x50 | 905x500x50 | 905x500x50 |
Dia.of the wheel(mm) | Φ125 | Φ125 | Φ125 |
Net weight(kg) | 106 | 106 | 120 |
Packing dimensions(mm) | 1010x520x370 | 1010x520x370 | 1010x720x380 |
Dia.of the cylinder(mm) | Φ40 | Φ40 | Φ40 |
Handle height off the ground (mm) | 970 | 970 | 970 |
Load in 20'container(PCS) | 100 | 100 | 70 |
Model | WP350A | WPS350AA | WP500A |
Load capacity(kg) | 350 | 350 | 500 |
Lowest height(mm) | 360 | 360 | 360 |
Max.height(mm) | 1300 | 1500 | 1580 |
Table dimensions(mm) | 905x500x50 | 905x500x50 | 905x500x50 |
Dia.of the wheel(mm) | Φ125 | Φ125 | Φ125 |
Net weight(kg) | 106 | 106 | 120 |
Packing dimensions(mm) | 1010x520x370 | 1010x520x370 | 1010x720x380 |
Dia.of the cylinder(mm) | Φ40 | Φ40 | Φ40 |
Handle height off the ground (mm) | 970 | 970 | 970 |
Load in 20'container(PCS) | 100 | 100 | 70 |
